Pwodwi
Log Fraisage machin Portable Sawmills
Log Fraisage machin Portable Sawmills se yon bon solisyon pou moulen bwa k ap travay.
Fonksyon
Log Fraisage machin Portable Sawmills se yon bon solisyon pou moulen bwa k ap travay.
Sawmill machin se yon ekipman mekanik apwopriye pou pwosesis bwa. Fonksyon prensipal la se koupe bwa nan gwosè ak fòm ki nesesè yo, ki ka satisfè bezwen yo nan fabrikasyon mèb, konstriksyon, bilding bato ak lòt jaden.
WÈ
|
Modèl |
HS26G |
HS31G |
HS26E |
HS31E |
|
Pouvwa |
Gazolin 9HP (LIFAN, demaraj manyèl) |
Gazolin 15HP (LIFAN, demaraj manyèl) |
Motè elektrik 5.5KW |
Motè elektrik 7.5KW |
|
Deplasman |
301cc |
420cc |
400V 50HZ 3faz |
|
|
Koupe kapasite |
660 * 178 * 2794mm |
790 * 178 * 2794mm |
660 * 178 * 2794mm |
790 * 178 * 2794mm |
|
Ankadreman |
4pcs |
4pcs |
4pcs |
4pcs |
|
Gwosè lam |
3690*34*0.9mm |
3960*34*0.9mm |
3690*34*0.9 mm |
3960*34*0.9mm |
|
Gwosè estanda tras |
4000 × 900mm |
4000 × 1030mm |
4000 × 900mm |
4000 × 1030mm |
|
Anbalaj |
2080 × 570 × 830mm |
2150 × 570 × 830mm |
2080 × 610 × 810mm |
2150 × 610 × 810mm |
|
Vitès koupe an sekirite |
13-15s/m |
13-15s/m |
||
|
Vitès lam |
17m% 2fmin |
17m% 2fmin |
||
|
Distans dan |
22mm (0.86″) |
22mm (0.86″) |
||
|
Lam wou Dia. |
480 mm (18.8% e2��) |
480 mm (18.8% e2��) |
||
|
Dimansyon |
4064*1778 * 1800mm (160″*70″*71″) |
4064*1778 * 1800mm (160″*70″*71″) |
||
|
Pwa |
400% 2f430kg |
430% 2f450kg |
||
TRELÈ
|
Modèl |
HST4-26 |
HST6-26 |
HST4-31 |
HST6-31 |
|
Aks trelè |
50x50mm |
50x50mm |
50x50mm |
50x50mm |
|
Gwosè trelè (L * W * H) |
3970({{1}mm drawbar)x900x700mm |
6000({{1}mm drawbar)x900x700mm |
3970({{1}mm drawbar)x1030x700mm |
6000(+1000mm drawbar)x1030x700mm |
|
Wou trelè ak defans |
165/70R13 |
165/70R13 |
165/70R13 |
165/70R13 |
|
Kapasite chaje trelè |
1500kg |
1500kg |
1500kg |
1500kg |
|
Limyè trelè |
Ki ap dirije twous limyè |
Ki ap dirije twous limyè |
Ki ap dirije twous limyè |
Ki ap dirije twous limyè |
|
Jack nivelman trelè |
6pcs |
8pcs |
6pcs |
8pcs |
|
Trelè boul kouple |
2″ (50mm) |
2″ (50mm) |
2″ (50mm) |
2″ (50mm) |
|
Fini |
Galvanize |
Galvanize |
Galvanize |
Galvanize |
|
Log loading ranp |
Max. 1350kg |
Max. 1350kg |
Max. 1350kg |
Max. 1350kg |
|
Log loading winch |
1200 liv |
1200 liv |
1200 liv |
1200 liv |
|
Pwa |
430kg |
470kg |
430kg |
470kg |
Tèt la deplase monte ak desann sou kanal asye galvanised atravè yon sistèm manivèl trè fasil. Se lam la kenbe wile pa itilize yon sistèm degoute dlo. Sa a anpeche sèv degoute lam ou.
Ki jan yo sèvi ak yon syaj
1. Preparasyon: Prepare bwa ki nesesè yo epi asire bwa a pa pral souke oswa glise.
2. Ajiste: Ajiste lam la wè nan wotè ak ang ki apwopriye yo.
3. Chaje bwa: Mete bwa a pou koupe nan machin syaj la.
4. Kòmanse: Kòmanse pwosesis la koupe ak vitès fiks.
5. Ranpli: Apre koupe a fini, fèmen pouvwa a.
Anbalaj la se anbalaj regilye pou Log Milling Machinery Portable Sawmills, anbalaj Customized ki disponib.
Baj popilè: boutèy demi lit fraisage machin pòtab sawmills, Lachin boutèy demi lit fraisage machin pòtab sawmills manifaktirè, Swèd, faktori
